Schneider Electric Merlin Gerin Powerpact 4 MGP2003X
200A 36kA Triple Pole Moulded Case Circuit Breaker (MCCB)
The range of wall and floor mounted Powerpact 4 panelboards is designed, manufactured and tested to BS EN 60439-1. The structures are rigid sheet steel finished in a cream colour epoxy powder (RAL 9001)
All the boards contain a unique connection system which ensures that all busbar/breaker connections are tightened to the correct torque. The system comprises a tightening bolt head which shears off when the correct torque is reached. Facilities are provided to enable the breaker to be repositioned at a later time if so required.
The breaker range comprises single pole, single pole with switched neutral, double pole, triple pole and three pole with switched neutral and four pole. Incoming device ratings up to 1600A and outgoing ratings up to 630A.
The extremely flexible board design allows 1, 2, 3 and 4 pole breakers to be positioned in any order in the busbar stack thus allowing maximum use of the available space and also allowing breakers feeding associated loads to be positioned together.
