Wylex DSF100M Amendment 3 All Metal Single Phase Switch Fuse With Cartridge Fuse 100A 240V – Replaces 110M

Wylex DSF100M Amendment 3 All Metal Single Phase Switch Fuse With Cartridge Fuse 100A 240V

Description

Wylex DSF100M

Amendment 3 All Metal Single Phase Switch Fuse With Cartridge Fuse 100A 240V

  • L:302mm x W:178mm x D:111mm
Product Information

The Wylex DSF100M is a dedicated 100A all metal sub main switch fuse designed to be used in domestic premises making the installation and connection of sub mains or system extensions quick and easy. Particularly suited to when larger single occupancy buildings are being converted into several individual apartments

Fully Amendment3 compliant ensuring it meets the latest fire regulations it supplied complete with a 100A BS1361 fuse fitted. The enclosure is finished in low smoke & fume paint includes a metal door that is screw retained.

Features and Benefits
  • Enclosed in a robust all metal (non combustible) enclosure
  • Screw retained cover
  • 32mm standard knock out for cable gland – top & bottom
  • Dual screw terminals throughout
  • Metal Door and Robust metal enclosure (1.0mm Thick) Steel Construction
  • Live and Neutral cable capacity 16mm² min, 35mm² max
  • 16mm Earth terminating point inside enclosure
  • Supplied complete with fuse (100A, 80A or 60A)
  • Low smoke & fume paint finish
  • Lockable mechanism for isolation safety purposes
  • Rotating fuse carrier for easy withdrawal
